Punkty mocujące

Uchwyt do przyspawania AOW

 DOR
[t]
MBL
[kN]
E
[mm]
D
[mm]
F
[mm]
B
[mm]
A
[mm]
L
[mm]
Masa
[kg/szt.]
Spoina
a min
[mm]

 1,1243,96313,5374038370,4010
 2,078,57314,5424240400,4512
 3,15124,07517,5424543440,7514
 5,3208,09422,5565560491,4518
 8,0314,011227626970662,3522
 15,0588,015434869688885,3530

Hak do przyspawania DZG

DOR
[t]
MBL
[t]

[mm]

[mm]

[mm]
G
[mm]
L
[mm]

[mm]
Masa
[kg/szt.]

278,5233436,52681910,80
3117,7313638301151051,25
5196,14543,548361591312,55
8314,0505149321651353,25
10392,3545548452021685,60

Śruba z uchem obrotowo-uchylnym WSI

Rozmiar M
[mm]
DOR [t]MBL
[kN]
A
[mm]
B
[mm]
C
[mm]
D
[mm]
E
[mm]
L
[mm]
H
[mm]
W
[mm]
Masa
[kg/szt.]

90°
M 80,60,323,55031161344135336,50,40
M 100,90,4535,35031161344185336,50,43
M 1210,539,25031161344185336,50,44
M 1621,1278,55031161344205336,50,46
M 2042157,072321916563069501,00
M 246,33,15247,185382218663079571,45
M 3010,65,3415,8843823,52082359866,52,20
M 30 D11,88462,91145330219535110803,55
M 3611,88462,91134927228650108803,75
M 421510588,4115492825,59250108804,15

Uchwyt do przykręcania AOS



DOR

T

MBL

kN

A

mm

B

mm

D

mm

F

mm

K

mm

H

mm

M

mm

L

mm

W

mm

Masa

kg/szt



1

39,2

36,4

72

13,5

27

105

42

15,3

125

40

0,5



3,15

124,0

40,6

90,5

17

33,5

130

47

21,4

153

45

0,8



5,3

208,0

49,6

110

22

41,5

160

58

25

186

54

1,7


Śruba z uchem wg DIN 580

Ø D
[mm]
DOR
[t]
A
[mm]

[mm]

[mm]

[mm]
M
[mm]
Masa
[kg/szt.]

M 6*0,078204920130,06
M 80,148204920130,06
M 100,2310256225170,11
M 120,34123073,53020,50,18
M 14*0,4914358935270,35
M 160,714358935270,35
M 18*0,9164010140300,45
M 201,2164010140300,45
M 22*1,5205012650360,74
M 241,8205012650360,74
M 272,5246015465451,66
M 303,6246015465451,66
M 33*4,3246015465452,65
M 365,1287018275542,65
M 39*6,1328021085634,0
M 427,0328021085634,0
M 45*8,03890236100686,4
M 488,63890236100686,4
M 5611,542100265110788,8
M 6416,0481102981209012,4
M 72215913033614810522,5
M 20 x 21,2164010140300,45
M 24 x 21,8205012650360,74
M 30 x 23,6246015465451,66
M 33 x 24,3246015465452,65
M 36 x 35,1287018275542,65
M 42 x 37,0328021085634,0
M 48 x 38,63890236100686,4

*Śruby z uchem wykonane w oparciu o normę DIN 580


Nakrętka z uchem wg DIN 582

Ø D
[mm]
DOR
[t]

[mm]

[mm]
L
[mm]

[mm]
Masa
[kg/szt.]

M 80,1482036200,05
M 100,23102544250,09
M 120,34123054300,16
M 160,7143563350,24
M 201,2164070400,36
M 241,8205090500,72
M 303,62460108651,32
M 365,12870130752,08
M 427,03280146853,11

Śruba z uchem o długim gwincie WPI

Rozmiar M
[mm]
DOR
[t]
MBL
[kN]
B
[mm]
D
[mm]

[mm]
L
[mm]
Masa
[kg]

M 100,2512,2149281760,20
M 120,419,61812361760,25
M 160,839,22314451820,50
M 201,678,42617531820,85
M 242,5122,03623721761,55
M 304,0196,04828881792,85

Śruba z uchem o długim gwincie WPE

Rozmiar

DOR

[t]

MBL

[kN]

D

[mm]

A

[mm]

B

[mm]

C

[mm]

E

[mm]

F

[mm]

G

[mm]

Masa

[kg/szt.]

M 10x114

0,7

27,5

M10

35

8

18

63

114

9,5

0,11

M 12x152

1,18

46,3

M12

46

10

25,5

75

152

12,7

0,23

M 16x152

2,35

92,2

M16

58

13

32

78

152

15,9

0,44

M 20x152

3,26

127,9

M20

69

16

38

72

152

19,1

0,70

M 24x229

6,03

236,5

M24

93

21

51

105

229

25,4

1,70

M30x305

9,52

373,4

M30

112

25

63

108

305

31,8

3,35


Śruba z uchem kl. 8

Ø D
[mm]
DOR
[t]

[mm]
F
[mm]
L
[mm]

[mm]
M
[mm]
Masa
[kg/szt.]

M 60,46154517130,05
M 8181951,521150,05
M 1019,52464,524,5180,1
M 12212297530220,2
M 16413,534,59135270,3
M 20615,539102,540290,45
M 248205013050370,85
M 3012235915565461,6

Śruba z uchem linowym SLU

Rozmiar
M
[mm]
DOR
[t]
MBL
[kN]

[mm]

[mm]
D
[mm]
W
[mm]
Masa
[kg]

M 100,3316,2114205,5380,05
M 120,524,5128226,0400,06
M 140,839,2155256,5550,08
M 161,258,8175289580,1
M 201,678,52103510650,2
M 242,5122,62554512 800,4
M 304,0196,13005816870,9

Ogniwo z gniazdem DLU

DOR
[t]
MBL
[kN]
D
[mm]
H
[mm]
E
[mm]
G
[mm]
B
[mm]
A
[mm]
C
[mm]
W
[mm]
Masa
[kg/szt.]

1,0 - 1,351,01318160704412,021730,95
1,5 - 2,598,01525190835616,028871,40
3,0 - 5,0196,02037225866721,5381093,35
6,0 - 10,0392,030523301098231,0501609,40

Zaczep do kontenerów morskich KE

TypDOR
[t]
MBL
[kN]
A
[mm]
B
[mm]
S
[mm]
H
[mm]
Masa
[kg/szt.]
KE - R12,5490,54226,569189,54,2
KE - L12,5490,54226,569189,54,2
KE - S12,5490,54226,569,189,54,2

W przypadku zapotrzebowania na punkty mocujące niewymienione powyżej prosimy o wcześniejszy kontakt lub przesyłanie indywidualnych zapytań.
